950x680x2405mm Mental Vertical Column Drilling Machine for High Precision Drilling

Name: 950x680x2405mm Mental Vertical Column Drilling Machine for High Precision Drilling
Brand: TIMEWAY
Price: 16 USD

950x680x2405mm Mental Vertical Column Drilling Machine for High Precision Drilling Manufactures

Condition : New

type : Column Drilling Machine

Max. Drilling Dia. (mm) : 50

Range of Spindle Speed(r.p.m) : 52 - 1400 r.p.m

CNC or Not : Normal

Drilling Speed : 1400rpm

Place of Origin : China

Brand Name : TIMEWAY

Model Number : DC-50A, DC-40A, DC-35A

Voltage : 220V

Dimension(L*W*H) : 950x680x2405mm

Power (kW) : 3

Weight (KG) : 655 KG

Warranty : 1 Year

Key Selling Points : High Productivity

Showroom Location : Egypt, United Kingdom, United States, Italy, France, Philippines, Brazil, Peru, Russia, Spain, Thailand, Chile, UAE

Applicable Industries : Machinery Repair Shops, Construction works

Marketing Type : Hot Product 2019

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor

Product name : Radial Drilling Machine

Application : Metal Processing

Machine type : large Radial Drilling Machine

Model : DC-50A; DC-40A;DC-35A

Motor : 3KW

Color : Customizable

After Warranty Service : 1year

Certification : CE ISO

Max. drilling diameter : 50mm for mental drilling

Spindle Speed(r/min) : 52-1400r/min

Packaging Details : Wooden cases(can be fumigated)

Port : China Port

Supply Ability : 150 Set/Sets per Month

Price : $16,390.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Products Description

950x680x2405mm Mental Vertical Column Drilling Machine for High Precision Drilling

Features:

1. 3-phase with voltage for 220V-575V collocation
.
2. All main parts are made with quality cast iron
.
3. Single-speed motor, 12 step gear shift; main motor with break
.
4. Unload tool device and coolant, fender device
.
5. Drilling diameter above 35mm (including 35mm) with milling function
.
6. Strength spindle, large diameter column
.
7. Worktable could be rotated and could be inclined ±45°
.
8. Motor driven lifting of worktable
.
9. Digital readout for the display of speed and cutting depth for drilling diameter above 35mm (including 35mm)
.
10. Micro feed is available; Trochoid thin oil lubrication
.
11. Superior quality of gears with hardened and lapped gears of surface
.
12. Importable electrical components with CE, CSA and UL standard

Specification	Unit	DC-35A	DC-40A	DC-50A
Max. drilling & tapping dia.(steel)	mm	35	40	50
Distance between spindle axis to column	mm	340	360	360
Distance between spindle nose to table/base	mm	665/1195	590/1175	590/1170
Max. milling cutter dia.	mm	80	80	80
Swivel angle of table	°	45	45	45
Spindle taper	-	MT4	MT4	MT4
Spindle travel	mm	190	200	240
Spindle speed range	rpm	76-2065	52-1400	52-1400
Spindle speed step	steps	12	12	12
Spindle feed speed	mm/r	0.1,0.2,0.3	0.1,0.2,0.3	0.1,0.2,0.3
Spindle feed step	stpes	3	4	4
Column dia.	mm	140	160	180
Table size	mm	520x440	580x460	580x460
Main motor power	kw	1.5	2.2	3
Overall dimensions (LxWxH)	mm	849x545x2290	940x680x2405	950x680x2405
NW/GW	kg	565/615	620/675	655/710

- Key type drill chuck

- Connecting bar for drill chuck

- Shaft sleeve for taper shank tool

- Wedge for taper shank tool

- Double open end spanner

- Operation manual(English)

- Collet

- Milling cutter shank

- Cross worktable

- 125mm precision vice

Why Choose Us

Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
