Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness

Product Categories
Zhengzhou Timeway Machine Tool Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness

CNC or Not : Normal

Condition : New

Grinding Length(mm) : 580

Surface Roughness(μm) : 0.01 μm

Table Size(mm) : 305x1020

Table Travel (X) (mm) : 340

Table Travel (Y) (mm) : 1130

Year : 2023

Place of Origin : China

Brand Name : TIMEWAY

Voltage : 220/330V

Dimension(L*W*H) : 440x220x190 cm

Weight (KG) : 3200

Power (kW) : 4

Warranty : 1 Year

Key Selling Points : High Productivity

Showroom Location : Indonesia, Nigeria, Germany, UAE, Mexico, France, Japan, Australia, Viet Nam, Kenya, Morocco, South Africa, Canada, Russia, Uzbekistan

Marketing Type : Hot Product

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor, Bearing, Gearbox, Engine, Gear, Pressure vessel, Pump, PLC, Other

Applicable Industries : Manufacturing Plant, Energy & Mining, Retail, Food & Beverage Shops

Type : Surface Grinding Machine

After-sales Service Provided : Online Support

Name : Grinder Machine

Product name : Surface Finishing Polishing Grinding Machine

Usage : Surface Polishing

Keywords : Precision Surface Grinder Machine

Application : Grind Rail Surface

Color : White

Certification : CE ISO

Precision : High Precision

Packaging Details : Wooden cases(can be fumigated)

Port : China Port

Supply Ability : 150 Set/Sets per Month

Price : $17,000.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Products Description
SG-30100AH
Saddle Moving Type Surface Grinder:
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness
Specification
Unit
SG-30100AH
SG-30100AHR
SG-30100AHD
Table size
mm
305x1020
Electro magnetic chuck size
mm
300x1000
Distance from spindle to table
mm
580
Table cross travel
mm
340
Table longitudinal travel
mm
1130
Loading capacity (include chuck)
kg
400
Longitudinal feed speed
m/min
5-25
Table cross intermittent feed rate
mm/str
0.1-8
Table cross rapid feed speed
mm/min
990
Table cross feed of handwheel
mm/gra
0.02
Wheelhead vertical intermittent feed rate
mm/str
AH: -;
AHR: -;
AHD: 0.005-0.5;
Wheelhead vertical rapid feed speed
mm/min
AH: -;
AHR: 650;
AHD: 480;
Wheelhead vertical feed of handwheel
mm/gra
0.005
Spindle speed (50/60HZ)
rpm
1450/1750
Grinding wheel size
mm
350x40x127
Main motor power
kw
4
Machine dimensions (LxWxH)
cm
440x220x190
Package dimensions (LxWxH)
cm
295x222x221
Machine weight
kg
3200
Positive Comments From Customers
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness
Shipping
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness
Exhibitions
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness

TIMEWAY at EMO Hannover

TIMEWAY machine participates in the EMO Hannover exhibition every time, which is Europe's leading machine tool and metal processing technology exhibition. At the exhibition, TIMEWAY machine demonstrated its advanced machine tools and processing technology, as well as comprehensive solutions for different industries and application fields. These solutions include precision machining and production of high-quality metal parts for the automotive, aerospace, energy, and other sectors.
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness

TIMEWAY at CIMT

CIMT is held in China, the hometown of TIMEWAY machine, so TIMEWAY machine will participate in the CIMT exhibition every time. This is the China International Machine Tool Exhibition and one of the largest machine tool exhibitions in Asia. At the exhibition, TIMEWAY displayed its diversified machine tool products, including CNC machine tools, machining centers, gear processing machine tools, precision measuring equipment, etc.
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness

TIMEWAY at Metalloobrabotka

TIMEWAY machine participated in the Metalloobrabotka exhibition held in Moscow, which is a professional exhibition for the metal processing and machine tool industry in Russia and surrounding areas. At the exhibition, TIMEWAY machine booth attracted the attention of many exhibitors and industry experts. The company's professional team had in-depth exchanges with exhibitors and visitors from Russia and other countries and regions, sharing valuable experience and the latest industry trends. In addition, TIMEWAY machine has also participated in exhibitions in many countries and regions.
Company Introduction
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness
Factory Display：
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness
Text Introduction：
Precision Surface Grinder Machine SG-30100AH Saddle Moving Type 0.01 μm Surface Roughness
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
