406mm Grinding Length Saddle Moving Type Hydraulic Surface Grinding Machine

Name: 406mm Grinding Length Saddle Moving Type Hydraulic Surface Grinding Machine
Brand: TIMEWAY
Price: 25 USD

406mm Grinding Length Saddle Moving Type Hydraulic Surface Grinding Machine Manufactures

CNC or Not : Normal

Condition : New

Grinding Length(mm) : 406

Wheel Size(mm) : 813

Surface Roughness(μm) : 0.32 μm

Table Size(mm) : 406x813

Table Travel (X) (mm) : 910

Table Travel (Y) (mm) : 450

Year : 2023

Place of Origin : China

Brand Name : TIMEWAY

Voltage : As customer's required

Dimension(L*W*H) : 360x220x225cm

Weight (KG) : 3800

Power (kW) : 4

Warranty : 1 Year

Key Selling Points : Competitive Price

Showroom Location : Indonesia, Nigeria, France, Australia, Viet Nam, Egypt, Morocco, South Africa, Turkey, South Korea, Canada, Russia, Malaysia, Philippines, Tajikistan, Uzbekistan, Brazil, United Kingdom, Peru, Ukraine, Chile, Pakistan, United States

Marketing Type : Hot Product 2019

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor, Other

Applicable Industries : Manufacturing Plant, Energy & Mining, Construction works , Building Material Shops

Grinding wheel size : 350x40x127mm

Distance from spindle to table : 580mm

Loading capacity : 500kg

Longitudinal travel : 910mm

Cross travel : 450mm

Table cross micro feed rate : 0-1000mm/min

Wheelhead vertical rapid feed speed : 0-1000mm/min

Wheelhead vertical micro feed rate : 0.005mm/gra

Spindle speed : 1450rpm

Packing size : 3600x2200x2250mm

Packaging Details : Wooden cases(can be fumigated)

Supply Ability : 150 Set/Sets per Month

Price : $25,668.00/sets 1-2 sets

MOQ : 1 set

Contact Now

Products Description

406mm Grinding Length Saddle Moving Type Hydraulic Surface Grinding Machine

Features:

1.SG-CNC series saddle moving surface grinder, the table size covers 200x500, 250x500, 300x630, 300x1000, 400x800, 400x1000.

2. Well designed perfect symmetrical structure insure the machine is very suitable for precision grind. Saddle makes cross movement driven by AC servo motor (Y-axis), worktable make reversing movement driven by hydraulic or servo motor (X-axis), and spindle make elevating movement (X-axis) and is driven by AC servo motor.

3. SG-CNC2 model: Y/Z-axis numberical control and linkage, drove by AC servo motor and ball screw; X-axis drove by hydraulic.

4. SG-CNC3 model: X/Y/Z-axis numberical control and linkage, drove by AC servo motor and ball screw.

5. Precision grind spindle with preload high precision angular ball bearing and drive V3 motor, runs in maintenance-free, low vibration, and no noise.

6. Elaborately-designed closed safe guard with safety-switch, not only have good appearance but also safety operating field.

Specification	Unit	SG-4080CNC2
Table size	mm	406x813
Electro magnetic chuck size	mm	400x800
Table cross travel	mm	910
Table longitudinal travel	mm	450
Distance from spindle to table	mm	580
Loading capacity (include chuck)	kg	500
Table longitudinal feed speed	m/min	5-25
Table cross rapid feed speed	mm/min	0-1000
Table cross micro feed rate	mm/gra	0.005
Wheelhead vertical rapid feed speed	mm/min	0-1000
Wheelhead vertical micro feed rate	mm/gra	0.005
Spindle speed (50/60HZ)	rpm	1450
Grinding wheel size	mm	350x40x127
Main motor power	kw	4
Machine weight	kg	3800
Floor space (LxW)	mm	4500x2400
Packing size (LxWxH)	mm	3600x2200x2250

· Electronic handwheel

· Closed safe guard

· Work lamp
· Balancing arbor
· Standard grinding wheel
· Electrical magnetic chuck
· Built-in magnetic chuck controller
· Coolant tank
· Wheel flange and extractor
· Wheel dresser stand
· Operation manual (English)
· Leveling wedge and screw
· Lubrication system
· Tool box&tools

· Diamond pen

· Balancing stand

· Extra wheel flange

· Rear splashing guard
· Oil tank guard
· Dust exhaust
· Parallel wheel dresser
· Radius dresser
· Angle dresser
· Side dresser
· Sinusoidal magnetic table
· Electronic handwheel
· Magnetic separator
· Paper filter

Why Choose Us

Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
